A
The Tray is attached to and removed from
the frame by the metal brackets located
below the chest pad. To attach the tray slide
the metal bars into the receiving tubes to the
required depth and secure by tightening the
knobs (a) on either side.
7.2 How to attach the
tray in supine standing
7.3 Inserting Attachment
bolt
Insert the required attachment bolt (a)
along with the retention plate (b). Place a
rubber lid (c) on both, the top and bottom
of the sandal. Fasten using the four screws
(d) provided. To remove or replace the
attachment bolt, reverse this process.
A
1
2
3
B
D
C
C
D
