The Leckey Horizon Stander
footplates are split to allow independent
height and angle adjustment for exact
positioning of both feet. To adjust the
footplate height first loosen the allen bolts
(a) and then slide the footplate to the
required position and retighten securely.
To alter the angle of the footplate to
accommodate plantarflexion or dorsiflexion
simply rotate the coupling cylinder clockwise
or anti clockwise respectively (b).
The footplate is hinged at the front which allows
the sandals to be adjusted more easily and
can facilitate transfer from a seating position to
prone standing. To avoid any possible finger
nip issues lift the footplate at the notched area.
Use caution when lifting and
lowering the footplate as fingers
could become trapped.
8.4 Adjusting the
Standard Footplates
8.5 Adjusting the
Flip-up Footplates
A
B
