The Tray is attached to and removed from
the frame by the metal brackets located
below the chest pad. To attach the tray slide
the metal bars into the receiving tubes to
the required depth and secure by tightening
the knobs (a) on either side. There are limit
poppers in the end of the tray tubes to show
the maximum depth adjustment allowed.
These may need to be depressed to
remove the tray.
To adjust the height loosen the four knobs
(b), set the tray to the required position and
then retighten the knobs securely.
The tray angle can be adjusted by loosening
the plastic handle (c) on either side of the
tray, set the tray to the required angle and
tighten the plastic handles again securely.
8.11 Activity Tray
Adjustment – Supine
A
BB C
