3-6 Specifications
3.19 General
Auto Calibration: Ensures specified DC and timing accuracy is maintained for 1 year
minimum.
Auto Calibration Time: <500ms
Power Requirements: 90–132 V AC 45-440 Hz, and 180–250 V AC; 45–66 Hz; automatic
AC voltage selection, maximum power dissipation 150 VA–230 VA, depending on model
Battery Backup: Front panel settings retained for two years minimum
Warranty and Calibration: Three years; calibration recommended yearly
3.20 Physical Dimensions
Dimensions (HWD): 210 mm x 350 mm x 300 mm (8.3" x 13.8" x 11.8"); height excludes
scope feet
Weight: 8 kg (18 lbs.)
Shipping Weight: 12kg (27 lbs.)
3.21 Math Tools (Standard)
Simultaneously perform up to four math (signal) processing functions; traces
can be chained together to perform math-on-math.
average (summed to 4000 sweeps) product
Average (continuous weighted) ratio
difference reciprocal (invert)
enhanced resolution (to 11 bits) resample (deskew)
envelope rescale (with units)
FFT of 50 kpoint waveforms roof
floor sin x/x
identity sum
negate
