3.22 Measure Tools (Standard)
Automated measurements; Display any five parameters together with their average, high,
low, and standard deviations.
amplitude fall 90-10% period
area fall 80-20% Phase
base frequency rise 10-90%
cycle mean maximum rise 20-80%
cycle rms mean rms
cycles minimum sdev
delay +overshoot top
∆delay
–overshoot width
duty cycle peak-to-peak xamn
xamx
3.23 Pass/Fail
Test any five parameters against selectable thresholds. Limit testing is performed using
masks created on the scope or PC. Set up a pass or fail condition to initiate actions such as
hard-copy output, saving waveform to memory, GPIB SRQ, or pulse out.
3.24 Options
Extended math and Measurement: Adds math and advanced measurements for all general
purpose applications. Includes all standard math and measurement tools, plus the
following tools:
3.25 Extended math tools
Automated measurements; Display any five parameters together with their average, high,
low, and standard deviations.
absolute value integrate
differentiate square
exp (base e) square root
exp (base 10) trend (datalog)
log (base e) histogram (200 events)
log (base 10)
3.26 Cursor Measurements
Type From To
Relative time: First point on waveform Any other point on waveform
Relative voltage: Select voltage level Any other voltage level
Absolute time: Time and voltage relative to Ground and trigger
Absolute voltage Voltage Ground
Specifications 3-7
