Actuators
DIN MODULE ACTUATORS
These devices are suitable for centralised installation in
electrical panels and switchboards. Available in the 1, 2 and
4-relay versions for control of individual or double loads
(motors for electrical blinds), they are fitted with a load
control pushbutton to perform load operation tests.
With these actuators, the rear DIN adaptor and the front
cover can be removed to reduce the size and therefore allow
for installation in cable trays, junction boxes, false ceilings,
shutter boxes, etc.
Load connection clamps
Load control pushbutton
Configurator housing
DIN actuator for installation in switchboards
Example of switchboard installation
Removable
front cover
Removable adaptor for
installation on IN guide
in central units
Example of junction box installation
20 mm only
