Leica asp6025 User Manual

25
ASP6025 Tissue Processor
3. Instrument Components and Specications
1 - Basic instrument - processor module
2 - Basic instrument - reagent cabinet
3 - Cover ap for the paran baths
4 - Retort lid
5 - Monitor
6 - Left upper door
7 - Counter area
8.1 - Bolt handle for retort
8.2 - Unlocking mechanism switch for retort
9 - Drawer for RTU-bottles
10 - RTU-bottles with ller necks
(pack of 6)
11 - Left lower door
12 - Right lower door
Instrument components
3.4.1 Instrument components and accessories
13 - Active carbon lter
14 - Condensate bottle
15 - System bottles (pack of 9)
16 - Drip tray
17 - Paran melting station
18.1 - Spout for draining paran
18.2 - Spout for lling with reagents
19 - Retort
20 - Paran baths (3)
21 - Specimen basket
22 - Lid for specimen basket
23 - Castors for moving the instrument
24 - Cover ap for the active carbon lter
25 - Paran station lid
The specimens are processed in the stainless steel retort (19) at
the preselected pressure, vacuum, and temperature conditions.
There are nine system bottles (15) with a maximum filling
volume of 5 l in the reagent cabinet.
Additionally there are six RTU-bottles (10) housed in a separate
drawer (9) on the right side of the instrument.
(For additional information, refer to Chapter 4.4.7, Fig. 44).
Three paran baths, the paran station, and the retort com-
prise the inltration module.
Above it is the touchscreen with a USB port on the side and the
electronic components.
All electrical ports and the electronic interfaces are located on
the rear side of the instrument (Chapter 3.4.2, Fig. 3).
The cassettes to be processed are stored in three baskets (21),
each of which can hold up to 100 cassettes. If the baskets are
used with inserts (spirals), each basket can hold 80 cassettes.
