Leica ComGate10, Description of the System
17
Leica MS60/TS60
MS50/TS50/TM50
instrument cable
Interface cable GEV271
Leica GMX910 cable Interface cable GEV212
Leica GMX902 cable Interface cable GEV247
Interface cable GEV160 + ATEN UC-232A
Leica Nivel210 cable Interface cable GEV207
Cable features:
• Interface: ComGate10 - MS50/TS50/TM50
• Transmission: Data and power
• Type: Shielded
• Length: 2 m
• Wires: 4 + USB
• Lemo pins: 8
• Unterminated
• USB standard plug type A
Cable features:
• Interface: ComGate10 - GMX910
• Transmission: Data and power
• Type: Shielded
• Length: 5 m
• Wires: 5
• Lemo pins: 8
• Unterminated
Cable features:
• Interface: ComGate10 - GMX902
• Transmission: Power
• Type: Shielded
• Length: 2 m
• Wires: 2
• Lemo pins: 2
• Unterminated
Cable features:
• Interface: USB-serial converter - GMX902
• Transmission: Data
• Type: Shielded
• Length: 2.8 m
• Wires: 5
• Lemo pins: 8
• RS232 connector
• This data cable must be connected directly to the D-Sub 9 connector of the ATEN
UC-232A adapter.
Cable features:
• Interface: ComGate10 - Nivel210
• Transmission: Data and power
• Type: Shielded
• Length: 1.8 m
• Wires: 5
• Lemo pins: 5
• Unterminated
