Leica ComGate10, Description of the System
18
Leica Nivel220 cable Interface cable GEV207
DB9 cable (RS232) plus RS232/485 converter
Power supply cable
TP meteo sensor
RS485
DB9 cable (RS232) plus RS232/485 converter plus USB-to-serial converter
Ethernet cable Ethernet cable RJ45
Cable features:
• Interface: RS232/485 converter - Nivel220
• Transmission: Data and power
• Type: Shielded
• Length: 1.8 m
• Wires: 5
• Lemo pins: 5
• Unterminated
Cable features:
• Interface: ComGate10 - RS232/485 converter
• Transmission: Data
• DB9 male to DB9 female
• Connect this cable directly to a serial port of the ComGate10 using USB-to-serial
converter (ATEN UC-232A).
• Leica Geosystems delivers no RS232 cable.
• Leica Geosystems delivers no USB-to-serial converter (ATEN UC-232A).
• Leica Geosystems delivers no RS232/485 converter. It is a product of ICP DAS Co.:
http://www.icpdas.com.
Cable features:
• Interface: ComGate10 - RS232/485 converter
• Transmission: Power
• This cable must be organised locally.
Cable features:
• Interface: ComGate10 - RS232/485 converter
• Transmission: Data
• DB9 male to DB9 female.
• Connect this data cable directly to a serial port of the ComGate10 using USB-to-
serial converter (ATEN UC-232A).
• Leica Geosystems delivers no RS232 cable.
• Leica Geosystems delivers no RS232/485 converter. It is a product of ICP DAS Co.
(http://www.icpdas.com).
• Leica Geosystems delivers no USB-to-serial converter (ATEN UC-232A).
Cable features:
• Interface: Ethernet Switch - Webcam
• Transmission: Data
• Max length: 100 m
• The optional, externally mounted webcam must be connected by an Ethernet cable.
• Leica Geosystems delivers no Ethernet cable.
