Leica ComGate10, Description of the System
19
Warning device
cable
Warning device cable
Mobile internet/
WLAN antenna
cable
Antenna cable

For simultaneous use of mobile Internet and WLAN, two antennas of this type
are needed.
Power supply cable Power cable
Cable features:
• Interface: ComGate10 - warning device
• Connect the optional warning devices directly by standard cables to the
ComGate10. The cables must be organised locally.
• Only an appropriately trained and qualified specialist may install warning devices
with a ComGate10.
• Refer to chapter "5 Technical Data" for information on the specifications of the
digital output or to section "3.6 Sensor Connection and Setups".
Cable features:
• Connectors: 2 × SMA male
• Length: 5.0 m
• The antenna is directly connected to the wireless router by the included antenna
cable.
Cable features:
• Interface: ComGate10 - power supply unit GEV270
• Transmission: Power
• Wires: 2
• Power supply unit (GEV270)
