Leica ComGate10, Operation
31
Setup with TP
meteo sensor
RS485
Setup with warning
devices

Only an appropriately trained and qualified specialist may install warning
devices with a ComGate10.
ATEN UC-232A
RS232
RS232/485
Converter
722 411
GEV270
807 696
Power cable
TP meteo sensor RS485
837 816
14130_002
COMGT10LWEU
853 396
CT-AT467
853 397
a) ComGate10
b) Cable
c) Warning device
006192_002
abc
