5. Assembling the microscope
The microscope components
+)
are logically assembled
in this order:
• Only for microscopes with transmitted light illuminator
arm (chapter 5.8-5.10):
• Transmittedlightilluminatorarm
• Condenserwithcondenserhead
• Transmittedlightlamphousing
• DICmoduleandDICobjectiveprisms
• Specimenstage
• Eyepieces
• Objectives
• Incidentlightilluminator(LEDlamphousing)
• Equipmentfortheincidentlightturret
• Polarizerandanalyzer
When using other systems and advanced optical accesso-
ries, the sequence may vary.
Only a few commonly used screwdrivers and keys are
necessary for assembly; these are included in the delivery
package.
5. Assembling the Microscope
+) Depending on scope of delivery
14
