Table 2 - Electromagnetic Immunity
The Models Envisu 2300 is intended for use in the electromagnetic environment specified below. The
customer or the user of the Envisu 2300 Model should assure that it is used in such an environment.
Electromagnetic environment
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8kV contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
Floors should be wood, concrete or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30 %.
Radiated RF EM Fields
IEC 61000-4-3
3V/m
80 MHz – 2.7 GHz
80% AM at 1kHz
Proximity fields from RF
wireless communication
equipment
IEC 61000-4-3
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV, 100kHz repetition
frequency for power
supply lines
±1 kV, 100kHz repetition
frequency for input/output
lines
Mains power quality should be that of a
typical commercial or hospital
environment.
±0.5kV, ±1 kV line(s) to line(s)
±0.5 kV, ±1 kV, ±2 kV line(s) to
ground
Mains power quality should be that of a
typical commercial or hospital
environment.
Conducted disturbances
induced by RF fields
IEC 6100-4-6
Voltage dips,
IEC 61000-4-11
0% U
T
; 0.5 cycle At 0°, 45°, 90°,
135°, 180°, 225°, 270°, 315°
0% U
T
; 1 cycle
And
70% U
T
; 25/30 cycles
Single phase: at 0°
Mains power quality should be that of a
typical commercial or hospital
environment. If the user of the Envisu
2300 Model requires continued
operation during power mains
interruptions, it is recommended that
the Envisu 2300 Model be powered
from an uninterruptible power supply or
a battery.
Voltage interruptions,
IEC 61000-4-11
Mains power quality should be that of a
typical commercial or hospital
environment. If the user of the Envisu
