The "COLOR" function makes it possible to adapt the camera chip
to the ambient light so that color-neutral images can be acquired.
Adjusting the white balance manually (recommended)
1. Move the specimen out of the field of view so that only the illumina-
tion is seen.
2. Press the button on the remote control.
3. Call up the "COLOR" entry.
4. Set the "WB MODE" to "MANUAL".
5. If necessary, correct the values for "RED" and "BLUE" until the image
shows a uniform gray area.
6. Press the button to exit the menu.
COLOR (Manual White Balance)
Leica IC90 E User Manual The Camera Remote Control (Standalone Kit) 31
COLOR
EXPOSURE
RESOLUTION
SETUP CAMERA
SETUP USER
SETUP ETHERNET
SET WB
WB MODE
RED LEVEL
BLUE LEVEL
BLACK LEVEL
HUE
PRESS OK
MANUAL
SATURATION
Leica IC90 E
46
41
0
1
12
