Leica ICC50 E - The Basics

Leica ICC50 E or Leica ICC50 W User Manual The Leica ICC50 E or Leica ICC50 W 16

Your Leica HD camera has many possibili-
ties for various applications and condi-
tions of use. Below are some basic concepts to
help you get the most performance for your
application.
Power
Leica ICC50 E or Leica ICC50 W – 5 V/2 A
Power can be provided to the camera in the
following ways:
O USB power connector on the microscope
stand
O External USB power supply
O USB connectors PC
Modes of use
1. SD mode
O capture onto SD card
O use remote control
2. WiFi mode (only available for ICC50 W)
O Wireless connection to wireless device (tablet,
phone, PC)
3. USB mode
O Cabled connection to PC
4. Ethernet mode
O Cabled connection to external network
5. Capture button
O Captures image onto the SD card
The Basics

Note direct connection to an HD display
is possible in all modes. Aspect ratio is
16:9 except in USB mode where the aspect ratio
is 4:3.
1 3
2 4
5
