Leica ICC50 E or Leica ICC50 W User Manual Get Set! 31
Ethernet Mode – Capturing and Adjusting Images Using a Network
1. Connect one end of an ethernet cable (not
provided) to the camera and the other end
of the cable to the ethernet connection in
your facility.
2. Be sure the camera is connected to a power
source – see power source section on
page 24.
3. Press the red power button.
4. The status light will blink red. Wait until
the status light is green and one of the
mode button's is also green. This may take
approximately 30 seconds.
5. If a mode button other than ethernet mode
is lit green, then press the ethernet button
and wait until both the status LED and the
ethernet LED mode button is green.
6. Follow the directions of your network
compatible device to connect to your facili-
ties network and select the camera.
7. Open the appropriate app on your mobile
device or appropriate software on your
wireless enabled PC for viewing, capturing,
and adjusting the camera image.
