Leica IP S - Print Specifications

18
Version 2.0, Revision I
Instrument Components and Specifications
3
Printing speed
1
:
Printing batch jobs: 14 slides/minute (two line printing)
Single-slide printing: 10 s per slide
Ink cartridge capacity
2
: approx. 60,000 printouts or 3.5 months
Flash bulb lifetime: approx. 150,000 flashes
Printing:
Print resolution
3
: 360 x 360 dpi / 180 x 180 dpi, adjustable
Printing medium: Glass specimen slide with coated field
76 x 26 mm, max. 1.2 mm thick
Print formats: Slide
Pressure surfaces: max. 25.4 x 18.0 mm
PC system requirements:
IBM-compatible PC
Processor clock frequency: min. 800 MHz
Main memory (RAM): min. 256 MB
Hard disk: min. 6 GB
CD-ROM drive
1 free serial port
Operating systems: Windows 7 (32 bit and 64 bit), Windows 8.1 (32 bit and 64 bit),
Windows 10 (32 bit and 64 bit)
1
) Average value – exact speed in each individual case depending on system configuration and
software used.
2
) Average value – exact number of slides in each individual case depending on quantity being
imprinted and on density of imprint.
3
) Measured in addressable dots per inch.
3.3 Print specifications
Only standard specimen slides with imprintable colored edges (→ "Fig. 5-1") can be imprinted in the
Leica IP S (→ "Fig. 5").
Printing directly onto the glass is not possible.
Specimen slides with the following dimensions can be processed: 76 x 26 mm, max. 1.2 mm thick.
