INTRODUCTION UNITY MOTORHOME
UNITY FLOOR PLANS
U24MB PASSENGER SIDE VIEW
1
Light
2
Refrigerator Vents
3
External Receptacle
4
Awning
1
3 56 8
9
10
4
67
2
10
U24MB DRIVER SIDE VIEW
1
Awning
2
Slide Out Room
3
Water Heater
1 2
3
4
5
5
6 7 8 9
5
Entrance Step
6
BBQ Hook-Up
7
Storage Compartment
8
Inverter and Storage Compartment
4
Diesel Fill
5
Storage Compartment
6
Sewer Hose Hatch (Behind Doors)
9
Furnace Exhaust
10
Generator Compartment
11
Ladder Option
7
Shore Power Connection
8
Utility Center
9
Sewer Termination
