MOTORHOME OPERATION UNITY MOTORHOME
ENTRY STEP ELECTRICAL DIAGRAM
STEP OVERRIDE SWITCH
Depress the top of the step override switch
1
, located
inside the coach entrance, to prevent the steps from
retracting when the coach door is closed�
NOTE: The vehicle ignition switch must be in the
“OFF” position for the step override switch to work.
1
STEP COVER (ON SPECIFIC MODELS)
When the coach door is closed, you can lower
hinged plate
2
by releasing the latch
3
.This plate
covers the steps, providing a safe and level oor
area (available on select models only).
2
3
