UNITY MOTORHOME INTRODUCTION
COACH SPECIFICATIONS
1� The height of the motorhome is measured from the ground to the top of the highest standard component
and is based on the UVW of a typically equipped motor home. The actual height of your motorhome may
vary depending on chassis, equipment, build variations or tire pressures. It is important that you know the
actual height of your motorhome�
2� The load capacity of your motorhome is designated by weight, not by volume, so you cannot necessarily
use all available space when loading your motorhome.
3� Tank capacities are based on measurements prior to tank installation. Slight variations may occur due to
tank shrinkage or expansion.
4� Actual lled propane tank capacity is 80% of listed capacity due to overlling prevention device on tank.
5� Exterior storage capacity is approximate. Total volume will decrease if motorhome is equipped with a
generator�
Chassis 3500 Sprinter
Engine - 3.0L V6 Blue TEC Diesel 188hp / 325 lb-ft
Torque
Transmission - 5 Speed Automatic
Turning Circle - 52.5'
Axel Ratio - 3.92:1
Tires - LT215/85R16
U24MB U24CB U24IB U24TB U24FX
GVWR - lbs (kg)
11,030 (5003) 11,030 (5003) 11,030 (5003) 11,030 (5003) 11,030 (5003)
GCWR - lbs (kg) 15,250 (6917) 15,250 (6917) 15,250 (6917) 15,250 (6917) 15,250 (6917)
GAWR Front- lbs (kg) 4,410 (2000) 4,410 (2000) 4,410 (2000) 4,410 (2000) 4,410 (2000)
GAWR Back - lbs (kg) 7,720 (3502) 7,720 (3502) 7,720 (3502) 7,720 (3502) 7,720 (3502)
Wheelbase - in (mm) 170” (4326) 170” (4326) 170” (4326) 170” (4326) 170” (4326)
*Length - ft (mm) 25’1” (7645) 25’1” (7645) 25’1” (7645) 25’1” (7645) 25’1” (7645)
**EXT. Width - ft (mm) 7’10.5” (2400) 7’10.5” (2400) 7’10.5” (2400) 7’10.5” (2400) 7’10.5” (2400)
INT. Width - ft (mm) 7’5” (2260) 7’5” (2260) 7’5” (2260) 7’5” (2260) 7’5” (2260)
***EXT. Height Incl. A/C- ft (mm) 10' 7"(3225) 10' 7"(3225) 10' 7"(3225) 10' 7"(3225) 10' 7"(3225)
INT. Height - ft (mm) 6' 5"(1958) 6' 5"(1958) 6' 5"(1958) 6' 5"(1958) 6' 5"(1958)
Fresh Water Tank Cap. - gal (L) 24 (91) 30 (114) 30 (114) 30 (114) 24 (91)
Black Holding Tank Cap. - gal (L) 29 (110) 29 (110) 29 (110) 29 (110) 29 (110)
Grey Holding Tank Cap. - gal (L) 37 (140) 37 (140) 37 (140) 37 (140) 37 (140)
Fuel Cap. - gal (L) 26.4 (100) 26.4 (100) 26.4 (100) 26.4 (100) 26.4 (100)
Propane Cap. - gal (L) 15 (57) 15 (57) 15 (57) 15 (57) 15 (57)
Exterior Storage Capacity 55 cu. ft. 36 cu. ft. 63 cu. ft. 54 cu. ft. 34 cu. ft.
* Bumper to bumper; add 4” for Ladder Option
** Outside to outside of rear fender skirts
*** Add 2” for Winegard WIFI Option and 3” for Roadtrip Satellite Option
