Leisure UNITY 2018 - Water Pump

102
WATER AND PLUMBING SYSTEM UNITY MOTORHOME
position
4
�
6� Turn on the water pump switch
7
�
7� Slowly open the cold water tap until the water
runs smoothly� Repeat with the hot water taps�
Always turn off the water pump switch
7
if
leaving the motorhome unattended for an
extended period of time and when driving
to prevent excessive damage and battery
discharge in the event of a leak.
NOTICE
NOTICE
POTABLE WATER
When a city water supply connection is not available,
ll the fresh water tank using the following procedure:
1� Fill a suitable water container with potable water�
2� Place the suction hose
8
attached to the winterize
by-pass valve into potable water container.
NOTE: The winterize by-pass valve
9
is located
in the exterior utility center�
8
9
3� Turn the winterize by-pass valve
9
to
“WINTERIZE” and water ll selector valve
2
to
water tank ll
3
�
4� Turn on the water pump switch
7
on the system
monitor panel�
5� Depress and hold the fresh water tank level
switch
5
to show the percent-full level on the
LED display
6
. Once the fresh water level reads
full on the LED display, turn off the water pump.
6� Turn the winterize by-pass valve
9
to “NORMAL
FLOW" and the water ll selector valve
2
to city
water
4
�
DISCONNECTING THE CITY WATER SUPPLY
1� Turn off the city water supply.
2� Relieve the water pressure in the line by opening
a faucet in the motorhome�
3� Disconnect the hose from the city water
connection
1
�
4� Replace the protective plug over the city water
connection
1
�
1
2
3
4
FILLING THE FRESH WATER TANK
CITY WATER
1� Connect the water hose to the city water
connection
1
�
2� Turn the water ll selector valve
2
to water tank
ll
3
�
3� Turn on the city water supply.
4� Depress and hold the fresh water tank level
switch
5
to show the percent-full level on the
LED display
6
. Once the fresh water level reads
full on the LED display, turn off the city water
supply�
5
6
7
10
5� Turn the water selector valve
2
to the city water
