APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME
4� Bed down with the headboard tilted out as
backrest
4
�
4
5� Rear seating (lock ottoman to prevent movement
while the vehicle is in motion)
5
�
5
6
Lock ottoman
6
in its storage position
to prevent movement while operating
motorhome.
CAUTION
LEISURE LOUNGE SEATING
(Available in U24MB and U24FX)
1� Bench conguration
1
�
1
2� Seats with the table conguration
2
�
2
3� Seats pulled out (Pull out seats before lowering
Murphy bed)
3
�
3
