5
MONO input channel
DSP / AUX
Control for the DSP / AUX send level.
Sends the signal both to the internal DSP and to the AUX output,
allowing also the use of an external effect (if needed).
The DSP / AUX send is POST-FADER: this means than the signal is
taken after the control of the channel FADER and therefore its level is
effected by the fader’s setting. For this reason, the DSP / AUX send is
suitable for the use with effect.
PAN
Centre-dented Pan pot for controlling the signal’s pan: regulates
stereo “position” of the signal with respect to the main L&R outputs. If
PAN is turned completely to the LEFT, the signal will only be sent to
MIX LEFT, if it’s turned completely to the RIGHT, the signal will only
be sent to MIX RIGHT. At intermediate settings, the signal is sent to
both MIX LEFT and RIGHT, but in different proportions.
LEVEL
Pot for controlling channel level: regulates the level of each channel
sent to the MIX L&R main outputs.
