impedance of 220 Ohms should be connected to this output. It is possible to connect this output also to
an external amplifier for monitoring.
PHONES LEVEL
Pot for controlling the level of headphone output.
TAPE OUT L&R
Two RCA connectors: send out the signal taken from MIX and normally intended for STEREO recording.
These outputs can be connected to the inputs of a recorder.
TAPE IN L&R
Two RCA connectors: receive external signals from STEREO tape recorders, CD player, DAT, etc. These
inputs can be connected to the outputs of your equipment.
TAPE IN
TAPE IN input level control: regulates the level of a signal arriving from an external tape recorder to
MIX L&R. During recording, set the TAPE IN control in the “0” (closed) position to avoid annoying and
“dangerous” feedback or signal loops.
MIX/TAPE
Button for the assignment of the TAPE IN signal to the MIX output:
• button UP (MIX) = the TAPE IN signal is sent only to the headphones output;
• button DOWN (TAPE) = the TAPE IN signal is sent is sent also to the MIX output.
LEVEL
LEDs for the display of the MIX L&R signal level.
The LEDs are of two different colors:
• green/SIGNAL = show the normal operative level of the signal;
• red/PEAK = show a too high signal level (OVERLOAD).
To ensure clean, distortion-free signals and to avoid damaging the components of your sound system,
try to avoid making the red LEDs lighting up repeatedly.
+48V
LED indicating when the +48V phantom power is switched on: this LED lights up when the button
on the connector panel on the rear of the mixer is pressed.
ON
LED indicating when the mixer is switched on: this LED lights up when the button on the connector
panel on the rear of the mixer is pressed.
MASTER section
