LENCO Auto Glide Installation & Setup Guide

1.0 PRODUCT OVERVIEW
4
AUTO GLIDE
NMEA2000 Engines J1939 Engines
¦ Yamaha ¦ Volvo Penta
(Non-EVC Engines)
(Command Link Plus requires NMEA 2000
¦ Yanmar
Yamaha Gateway P/N:6Y98A2D00000)
¦ Caterpillar
¦ Evinrude
¦ Cummins
¦ Honda
¦ Detroit Diesel
¦ Suzuki
¦ John Deere
¦ Volvo Penta (EVC Engines)
¦ Steyr
(With a Volvo NMEA2000 Gateway - Volvo P/N
3889757)
SmartCraft Engines
¦ Mercury - Verado
¦ Mercury - Optimax with SmartCraft ECU
¦ Mercruiser with SmartCraft ECU
¦ Cummins/Mercruiser w/ SmartCraft ECU
Available for these CANBUS-based engines:
¦ Boat must have CANbus based engine(s) (see list below)
¦ Boat must have NMEA 2000 GPS network or NMEA 2000 antenna receiver. NMEA
0183 will work, but will have slower signal response. Lenco offers a NMEA 2000 GPS
antenna receiver and optional stainless steel mounting bracket.
¦ Boat must have Lenco Single or Dual Trim Tab System with Lenco Electric Actuators
1.1 System Requirements
CAUTION
CAUTION
IMPORTANT INSTRUCTIONS AND FACTS ABOUT YOUR NEW AUTO GLIDE
BOAT CONTROL SYSTEM
** PLEASE READ ALL OF THE INSTALLATION INSTRUCTIONS IN THIS MANUAL BEFORE
PROCEEDING. YOU WILL NEED TO PRINT OUT YOUR APPLICABLE WIRING
SCHEMATIC / DRAWING / PARTS LIST FROM OUR WEBSITE BEFORE YOU BEGIN THE
INSTALLATION PROCESS.
** YOU MUST PERFORM ALL OF THE SET UP FUNCTIONS AFTER THE PROPER
INSTALLATION OF BUT BEFORE USING YOUR AUTO GLIDE SYSTEM
** YOU ARE RESPONSIBLE FOR:
(A) DETERMINING THAT YOUR SYSTEM IS A CANBUS BASED SYSTEM
(B) CONNECTING OUR NMEA 2000 CABLE TO ENGINE(S) (YOU MAY HAVE TO
CONTACT THE ENGINE MANUFACTURER)
(C) CONNECTING OUR CAN 2 CABLE TO A GPS NETWORK (IF APPLICABLE) (YOU
MAY HAVE TO CONTACT THE GPS MANUFACTURER)
WARNING
!
Rev 03-10-11
