Lennox Core Unit Controller

23
9.3.2. Report
This section provides service reports, system logs, system prole and user prole. All logs and reports and either be
downloaded to the via the W4
• Service reports - These reports are saved to the root directory of the USB storage device. In addition you can save the
report to the mobile device being used and either text or email.
• System Logs - These logs are saved to the root directory of the USB storage device. In addition you can save the report
to the mobile device being used or either e-mailed or use the device’s share feature. There is also an option for data
analytic uploads as well.
• SystemandUserProle-TheproleissavedtotherootdirectoryoftheUSBstoragedevice.Inadditionyoucansave
thereporttothemobiledevicebeingusedore-mailed.Thereisalsotheoptioninthissectiontoloadasystemprole
from USB as well.
REPORT
REPORT NAME
FILE NAME
SERVICE
REPORT
SYSTEM
LOGS
SYSTEM
PROFILE
USB STORAGE
USER
PROFILE
MOBILE
SAVE
SHARE
USB
SAVE
SHARE
REPORT NAME
FILE NAME
MOBILE
SAVE
SHARE
USB
SAVE
SHARE
SAVE USER PROFILE
LOAD USER PROFILE
Figure 25. Report Menu Structure
9.3.3. Advanced Control
The interface will allow for the ability to remote reset the controller.
• Theinterfaceshallpresentaconrmationdialogtotheuserbeforeproceedingwiththeresetcommand
• The interface shall indicate to the user that re-pairing will be necessary following the reboot (assuming this is necessary)
The component test functionality includes a support a “ClearDelays” functionality.
The clear delays functionality will clear timers in the CORE Control System.
The interface supports a “clear lockouts”.
Features are:
• Remote Reset
• Clear Delays
• Controller Lockout - Locked or unlocked.
