Lennox Core Unit Controller User Manual

36
11. Parts and Kits
Table 10. Parts and Kits Available for CORE Unit Controller
Description Catalog number Description Catalog number Description Catalog number
CORE Unit Controller
Replacement kit
14V60 USB service kit tube 59W52 SmartWire™ Field
Termination kit
59W57
LCD Display Replacement
Kit
10X85 CORE Unit Controller
battery (10-pack)
59W53 Lennox Prodigy 2.0 USB
Memory Stick (5-pack)
59W59
CORE Unit Controller cover 10X86 BACnet Replacement kit 59W51
12. Service Report Example
===================================================
USB SERVICE REPORT
===================================================
Service Date 04:03:2014
Service Time 19:26:35
Serial No.
Software Version 08.00.0009
Hardware Version
Unit Number UNIT 1
SBUS Address 2
BACnet Address 2
Catalogue Number
Model Number LGH060H4EH1Y
CONFIGURATION ID 1 NTNNNNLN
CONFIGURATION ID 2 NNNNNNNNN
Status IDLE
===================================================
Runtime Data
Total Power On 23 HRS 8 CYCLES
Before Install 0 HRS −−−−−−−
Filter 12 HRS −−−−−−−
Belt 11 HRS −−−−−−−
Blower 12 HRS 50 CYCLES
Compressor 1 3 HRS 40 CYCLES
Compressor 2 4 HRS 27 CYCLES
Compressor 3 0 HRS 2 CYCLES
Compressor 4 0 HRS 3 CYCLES
Outdoor Fan 1 7 HRS 28 CYCLES
Outdoor Fan 2 2 HRS 22 CYCLES
Outdoor Fan 3 0 HRS 2 CYCLES
Outdoor Fan 4 0 HRS 3 CYCLES
Outdoor Fan 5 0 HRS 3 CYCLES
Outdoor Fan 6 0 HRS 3 CYCLES
POWER EXHAUST 0 HRS 0 CYCLES
Heat Stage 1 0 HRS 1 CYCLES
Heat Stage 2 0 HRS 1 CYCLES
Humiditrol 0 HRS 0 CYCLES
Free Cooling 0 HRS 4 CYCLES
UV Lamp 0 HRS −−−−−−−
===================================================
Sensor Data
OAT 66 degF
RAT 72 degF
DAT 73 degF
ZAT 78 degF
RH 50 %
CO2 460 ppm
===================================================
SmartAirFlow System Data
Calibrated On 04/03/2014 19:12:56
Supply Airflow Calibration Table
−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−
PWM(%) Speed(rpm) Airflow(cfm)
−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−
20 480 1031
30 570 1274
40 660 1493
50 750 1687
60 840 1857
70 930 2004
80 1020 2126
90 1110 2223
100 1200 2297
Supply Airflow Targets
−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−
Mode Desired Airflow(cfm) PWM(%)
−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−
Cool High 1800 57
Cool Low 1300 31
Heat 2000 70
Ventilation 1200 27
Smoke 2000 70
Economizer Differential Pressure(@ 2000 Supply
Airflow(cfm))
−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−
Damper Position (%) Diff.Pressure(in.H20)
−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−
0 0.39
50 0.23
100 0.06
Outside Airflow Targets
−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−
Minimum Outside Air/Minimum DCV: 200 cfm
Maximum DCV: 0 cfm
Minimum CO2: 7
00 ppm
Maximum CO2: 1200 ppm
===================================================
Alarm/Status Log
(143) 04:03:2014 19:26:13 RESET DAMPER PRESSURE
(141) 04:03:2014 19:26:13 RESET CFM TARGET TOO
HIGH
(143) 04:03:2014 19:06:19 SET DAMPER PRESSURE
(141) 04:03:2014 19:06:19 SET CFM TARGET TOO
HIGH
( 82) 04:03:2014 19:06:18 RESET CONTROLLER RESET
( 82) 04:03:2014 19:06:18 SET CONTROLLER RESET
(143) 04:03:2014 18:59:41 SET DAMPER PRESSURE
(141) 04:03:2014 18:59:41 SET CFM TARGET TOO
HIGH
( 82) 04:03:2014 18:59:40 RESET CONTROLLER RESET
( 82) 04:03:2014 18:59:40 SET CONTROLLER RESET
(143) 04:03:2014 18:35:19 SET DAMPER PRESSURE
(141) 04:03:2014 18:35:19 SET CFM TARGET TOO
HIGH
(148) 04:03:2014 18:21:36 RESET SMART AIRFLOW
CONFIG ERROR
(170) 04:03:2014 18:21:36 RESET POWER EXHAUST
UNCONFIGURED
(165) 04:03:2014 18:21:36 RESET ECONOMIZER
UNCONFIGURED
( 85) 04:03:2014 18:21:36 RESET INCORRECT
HUMIDITROL SETTINGS
(132) 04:03:2014 18:21:24 RESET VFD BYPASS
UNCONFIGURED
(148) 04:03:2014 18:21:23 SET SMART AIRFLOW
CONFIG ERROR
(132) 04:03:2014 18:21:23 SET VFD BYPASS
UNCONFIGURED
(170) 04:03:2014 18:21:23 SET POWER EXHAUST
UNCONFIGURED
(165) 04:03:2014 18:21:23 SET ECONOMIZER
UNCONFIGURED
( 85) 04:03:2014 18:21:23 SET INCORRECT
HUMIDITROL SETTINGS
( 82) 04:03:2014 18:20:31 RESET CONTROLLER RESET
( 82) 04:03:2014 18:20:31 SET CONTROLLER RESET
( 82) 04:03:2014 18:16:32 RESET CONTROLLER RESET
( 82) 04:03:2014 18:16:32 SET CONTROLLER RESET
( 82) 04:03:2014 18:14:10 RESET CONTROLLER RESET
( 82) 04:03:2014 18:14:10 SET CONTROLLER RESET
( 82) 04:03:2014 18:14:09 RESET CONTROLLER RESET
( 82) 04:03:2014 18:14:09 SET CONTROLLER RESET
=====================================================
END OF REPORT
