Lennox Core Unit Controller User Manual

88
16. Quick Start Guide
CAUTION
Check rooftop unit electrical power for proper voltage and phasing. Check gas train components.
a. Turn on unit and dismiss alarm messages as necessary.
b. FollowSETUP>INSTALLmenutoproperlycongureunit
c. Be sure unit is in normal operating mode as seen in display (COOLING, HEATING, IDLE, etc).
d. To verify operation use SERVICE > TEST menu.
Control Mode Menu Setup Needed Tips
THERMOSTAT (Factory set for 2-stage thermostat) Check LEDs for signals.
BACnet
SETUP > NETWORK INTEGRATION > NETWORK WIZARD > NETWORK
TYPE = BACNET MS/TP
• Setupinformationtobeveriedwith
integrator.
• Follow wiring instructions including network
termination
• Remember to set MAC address 0-127
• Expert level BACnet service manual available.
LonTalk SETUP > NETWORK INTEGRATION > NETWORK WIZARD > = LONTALK
• Setupinformationtobeveriedwith
integrator.
• Follow wiring instructions including network
termination
• XIFleavailable.NeuronIDonsticker.
• Expert level LonTalk service manual available.
Damper SETUP > TEST & BALANCE > DAMPER
• Verify damper minimum positions
• Refer to Economizer section of manual for
more detail
Local Mode
SETUP > NETWORK INTEGRATION > NETWORK WIZARD > RTU
STANDALONE
• Give unit time to start-up.
• Humidity control requires sensor or error code
7649
Dehumidier
DehumidiersetupwillbedoneduringtheSETUP>INSTALLwizard.It’sthe
last part of that wizard.
• Three possible connections, LOCAL
SENSOR, NETWORK SENSOR and
REHEAT DI4.
• Analog sensor wiring is polarity sensitive
Blower
Change motor torque; see
SETUP > TEST & BALANCE > BLOWER
• Final motor CFM should be set by Test and
Balance technician
• Blower charts are located in the unit
installation instruction.
