Lennox Core Unit Controller User Manual

27
RTU
OPTIONS
BLOWER ON
POWER
EXHAUST
EXTERNAL ENABLE
SEARCH
VAV
SUMMARY
EDIT
PARAMETER
OCCUPIED
ALWAYS
SET POWER EXHAUST
ECONOMIZER TRAVEL
SETPOINTS
SET POWER EXHAUST
BUILDING PRESSURE
SET DAMPER FRESH AIR
TEMPERING SETPOINTS
AIRFLOW
MISCELLANEOUS
HEATING
COOLING
ECONOMIZER
CONTROL OPTIONS
PERFORM A MANUAL SEARCH FOR A SPECIFIC PARAMETER (NOTE: NOT ALL
PARAMETERS CAN BE ACCESS THROUGH THE EDIT PARMETER TOOL)
Figure 29. Settings - Power Exhaust and Edit Parameter
9.4.2. Install
The mobile application provides a menu to run “New Unit Setup”.
• New Unit setup if chosen shall direct the user towards the install menu.
• The mobile application shall provide a menu to run “Install New M4” (CORE Unit Controller).
• Install new CORE Unit Controllerwillrstconrmwiththeuserifitisokayto“ClearallConguration”.
• Iftheuserconrmsthatitisokayto“ClearAllConguration”,theappshallasktheuseriftheyaresure.
• Iftheuserconrms,themenudirectstheusertowardstheSetup>RTUMenu>INSTALL.
• If the user cancels at any point, they shall be taken back to the Setup >RTU Menu > INSTALL.
INSTALL
NEW UNIT SETUP
SELECT
INSTALL
OPTION
INSTALL NEW M4
SEE FIGURE 9 FOR ADDITIONAL
INSTALL SETTING.
DATE AND
TIME
RTU NAME
MODEL NUMBER
SERIAL NUMBER
CATALOG NUMBER
CONFIGURATION ID 1
CONFIGURATION ID 2
YES OR CANCEL CONFIRM AGAIN
Figure 30. Settings - Install
