Table 12. CORE Control System Unit Parameters
Control
Parameter
No
Screen Name
Parameter Short
Description
Control Value
Units Description
Min. Default Max.
109
SMOKE ALARM
CONTROL
Smoke Alarm
Control
0 0 13 Option
Smoke alarm control options.
• 0 = Blower off, exhaust fan off and
fresh air damper closed.
• 2 = Blower off, exhaust fan on and
fresh air damper closed.
• 9 = Blower on, exhaust fan off and
fresh air damper opened.
• 10 = Blower on, exhaust fan on and
fresh air damper closed.
• 11 = Blower on, exhaust fan on and
fresh air damper opened.
110
ERR TIME OFF
DELAY
Error Time Off
Delay
64 300 1800 Seconds Off time delay if a “no-run” error occurs.
111
COOL STAGING
OPTION
Cooling Staging
Option
0
Default may
be altered at
factory test.
4 Option
Cooling staging options:
• 0 = No cooling operation
• 1 = Wired thermostat operation,
Two cooling stages and units with
Economizers
> Y1 = Free Cooling,
> Y2 = Adds all mechanical
stages.
• 2 = Wired thermostat operation.
Two cooling stages and Units with
Economizers
> Y1 - Free Cooling
> Y2-addsrststageof
mechanical.
• 3 = Wired thermostat operation.
Three cooling stages.
> Y1only-rststage,
> Y2 only - second stage,
> Y1+Y2 - third stage.
NOTE: Units with Economizers Y2 only
adds rst stage of mechanical,
Y1+Y2 adds rst and second
stage of mechanical.
• 4 = Discharge air control. Up to four
stages.
Block 5 Miscellaneous Parameters
112
HEAT STAGING
OPTION
Heating Staging
Option
0 2 2 Option
Heating staging options:
• 0 = No heating operation.
• 1 = Discharge air control with up to
four stages.
• 2 = Thermostat operation.
113
EN RET AIR TMP
LMT
Enable Return Air
Temperature Limit
0 0 1 Option
• Enables return air temperature limit
option.
• Return air limits may be used
for limiting zone temperatures.
Continuous fan operation
recommended.
114
COOL RET AIR
LIMIT
Cooling Return
Air Limit
60 65 80 °F
• Return air limit for cooling. If the
return air cooling limit is exceeded,
the cooling demands are interrupted.
• Parameter 113 must be set to 1 to
enable.
