Lennox Core Unit Controller

65
Table 12. CORE Control System Unit Parameters
Control
Parameter
No
Screen Name
Parameter Short
Description
Control Value
Units Description
Min. Default Max.
228
CL LO CFM
CALIB
AdvancedAirow
Low Speed
Calibration
-1200 0 1200 Count
• ApplicabletoStandardEfciency3-
to 6-ton units only.
• If the absolute value of this
Parameter is greater than Parameter
17. then this is not considered in
target calculation.
229 CL HI SPD CALIB
Advanced
AirowHiSpeed
Calibration
-1200 0 1200 Count
• ApplicabletoStandardEfciency3-
to 6-ton units only.
• If the absolute value of this
Parameter is greater than Parameter
14, then this is not considered in
target calculation
230
CL MED LO SPD
CALIB
AdvancedAirow
Medium Speed
Calibration
-1200 0 1200 Count
ApplicabletoStandardEfciency3-to
6-ton units only.
231
CL MED HI SPD
CALIB
AdvancedAirow
Medium High
Speed Calibration
-1200 0 1200 Count
ApplicabletoStandardEfciency3-to
6-ton units only.
232
HEAT CFM
CALIB
AdvancedAirow
Heat CFM
Calibration
-1200 0 1200 Count
ApplicabletoStandardEfciency3-to
6-ton units only.
233 VENT CFM CALB
Advanced
AirowVentCFM
Calibration
-1200 0 1200 Count
ApplicabletoStandardEfciency3-to
6-ton units only.
234
LO SP CFM
ALARM SP
AdvancedAirow
Low Speed CFM
Alarm Set Point
15 25 100 %
ApplicabletoStandardEfciency3-to
6-ton units only.
235
LO SP CFM
ALARM EU
AdvancedAirow
Low Speed CFM
Alarm Evaluation
0 1800 3600 Seconds
ApplicabletoStandardEfciency3-to
6-ton units only.
236
NO AIRFLOW
ALARM EU
AdvancedAirow
NoAirowAlarm
Evaluation
0 20 300 Count
ApplicabletoStandardEfciency3-to
6-ton units only.
237
OUTDOOR AIR
TARGET
Outdoor Air Target 0 0 750 CFM
ApplicabletoStandardEfciency3-to
6-ton units only.
238
OUTDOOR CFM
CALIB
AdvancedAirow
Outdoor CFM
Calibration
-600 0 600 Count
ApplicabletoStandardEfciency3-to
6-ton units only.
239
LO OD CFM
ALARM SP
AdvancedAirow
Outdoor CFM
Alarm Set Point
15 25 100 %
ApplicabletoStandardEfciency3-to
6-ton units only.
240
HI OD CFM
ALARM SP
Advanced
Air Flow High
Outdoor CFM
Alarm Set Point
15 25 100 %
ApplicabletoStandardEfciency3-to
6-ton units only.
241
MAX OD CFM
DCV SP
Advanced
AirowMaximum
Outdoor CFM
Demand Control
Ventilation Set
Point
0
600 (3-ton
Unit)
800 (4-ton
Unit)
1000 (5-ton
Unit)
2400 CFM
ApplicabletoStandardEfciency3-to
6-ton units only.
243
LO OD CFM
ALARM EU
Advanced Air
Flow Low Outdoor
CFM Alarm
Evaluation
0 1800 3600 Seconds
ApplicabletoStandardEfciency3-to
6-ton units only.
244
HI OD CFM
ALARM EU
Advanced
Air Flow High
Outdoor CFM
Alarm Evaluation
0 1800 3600 Seconds
ApplicabletoStandardEfciency3-to
6-ton units only.
245
OD DP ERR
ALARM EU
AdvancedAirow
Outdoor Air
Damper Error
Alarm Evaluation
0 1800 3600 Seconds
ApplicabletoStandardEfciency3-to
6-ton units only.
