Lennox eNeRGy Series User Manual

eNeRGy-IOM-2020.12-EN
• 34 •
Fix Speed Compressors
E022AH077F
E022AH087F
E022AH107F
E022AH140F
E024AH078F
E024AH088F
E024AH108F
E024AH126F
E024AH141F
E027AH160F
E027AH180F
Envelopes in °C
Cooling mode operating limits given for steady state running condition with noted temperature condition
Max. outdoor air temperature at indoor air temp. 27°C DB / 19°C WB
48
Max. outdoor air temperature at Min indoor air temp.DB / 47%HR
48
Max outdoor air temperature with unloading
52
53
49,5
51,5
51,5
52,5
49
49
51
49,5
49,5
Min. outdoor air temperature at indoor air temp. 20°C DB (*)
12,5
6,5
13,5
16
12
6
12,5
12,5
15
7
7
Min. outdoor air temperature at Max indoor air temp. 23°C DB / 47%HR
14
7
14
29
13
8
13
13
9
7
20
Max. entering air temperature at outdoor air Temp. 38°C DB
35
34
46,5
37,5
29,5
28,5
44
44
36,5
41
36,5
Max. entering indoor air temperature at Max outdoor air temp. 48°C DB /
40%HR
31
28
31
31
30
28
31
31
31
31
31
Min. entering indoor air temperature at outdoor air temp. 35°C DB
14
Min. entering indoor air temperature at Max outdoor air temp. 48°C DB /
40%HR
14
14
16
20
18
19
14
14
17
17
19
Heating mode operating limits given for steady state running condition with noted temperature condition
Min. outdoor air temperature at indoor air temp. 20°C DB
-15
Min. outdoor air temperature at Min indoor air temp. 5°C DB/ 59%HR
-3
5
-15
2
12
8
-15
-15
-15
Min. entering indoor air temperature
13
5
5
5
14
5
7
5
5
5
5
Max. entering indoor air temperature
25
Max. outdoor air temperature at Max indoor air temp. 25°C DB / 59%HR
29
23
29
23
26
24
30
29
23
24
24
Min. outdoor air temperature at indoor air temp. 20°C DB / 100%fresh air /
with electrical Std pre-heater
6
5
1
5
8
0
3
2
5
5
5
Min. outdoor air temperature at indoor air temp. 20°C DB / 100%fresh air /
with electrical High pre-heater
-4
5
-8
4
-2
-9
-5
-6
5
5
5
