Lennox S40 - Home and Status Screens Icon Descriptions

19
Home and Status Screens Icon Descriptions
Table 2. Home and Status Screens Icon Descriptions
Icon
Function or
Screen Text
Purpose
Menu Select this icon to prompt the user and installer menus.
1
Menu with
Notication
Icon
If there are one or more notications this icon will appear over the menu icon. The number in the center indicates how
many active notications are present.
Feels Like™
is Active or
Turning Feels
Like™ on
Optimizes and automates factors that affect comfort (including heating, cooling, and humidity) and creates the ideal
environment. It’s very similar to the “feels like” temperature on a weather report. If the “Feels Like™” feature is enabled,
Feels Like™ displays below the system name on the Home screen.
Smart Away is
Active or Away
is Active
When the Away icon is selected, the system will automatically use energy saving settings - heat-to 62 (16.5) and cool-
to 85 (29.5). Temperatures can be adjusted by pressing the available temperature setting (i.e., heat-to or cool-to). To
exit Away, press the Cancel icon. In a zoning system, all zones are set to a single heat-to and cool-too setting. Note
that when manually selecting Away from the Home screen, the Smart Away feature (if enabled under settings) will be
temporarily disabled until Away is canceled.
Heating System is heating the home. This animated icon will appear above the system name on the Home screen.
Cooling System is cooling the home. This animated icon will appear above the system name on the Home screen.
Humidifying
If humidication equipment is installed and congured, the system will display this message when adding humidity to the
air in the home.
Dehumidifying
The system can be used in cooling mode to help remove excessive humidity as determined by the user setting. Go to
Menu > Settings > Humidity > and turn on dehumidify. Then adjust the acceptable low and high humidity levels in the
home with the dehumidication set-point slider.
