Lenovo 20L5 - Left-Side View; Right-Side View

Lenovo 20L5
114 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
1 Infrared camera *
2 Microphones
3 Conventional camera * 4 Conventional camera with ThinkShutter (len cover) *
5 Power button 6 Fingerprint reader *
7 TrackPoint buttons 8 Trackpad
9 TrackPoint
®
pointing stick
10 NFC mark*
11 Screen (multi-touch screen on some models)
Left-side view
1 USB-Cconnector 2 USB-C connector (Thunderbolt3 compatible)
3 Connector cover
4 Docking-station connector
5 Fan louvers
6 Smart-card slot *
Right-side view
1 Audio connector
2 USB 3.1 connector Gen 1
3 HDMIconnector
4 Always On USB 3.1 connector Gen 1
5 Ethernet connector 6 Media-card slot
7 Security-lock slot
