Applying labels to the base cover assembly:
The following illustration shows the location of each label.
1 FCC label 2 GEO label
3 S/N label
4 IMEI label
5 System label 6 Certificate of authenticity label
7 SVT label
8 Asset tag
9 China WWAN/modem label 10 GML label
11 Country label
1040 Memory module
Note: Before you start the servicing, disable the built-in battery. See “Disabling the built-in battery” on page
64.
For access, remove these FRUs in order:
• “1010 Removable battery” on page 64
• “1030 Base cover assembly” on page 65
68
T480 Hardware Maintenance Manual
