• “1070 Wireless-LAN module” on page 73
• “1090 Keyboard” on page 75
• “1100 Coin-cell battery” on page 77
• “1110 Speaker assembly” on page 78
• “1120 Built-in battery” on page 79
• “1130 Smart-card reader assembly” on page 80
• “1140 I/O bracket and RJ45 bracket” on page 81
• “1150 Thermal fan assembly” on page 82
• “1170 System board” on page 85
• “1180 Power-button card” on page 88
• “1190 Fingerprint-reader card” on page 88
• “1200 NFC module” on page 90
• “1210 LCD unit” on page 90
2010 LCD bezel sheet
Note: Before you start the servicing, disable the built-in battery. See “Disabling the built-in battery” on page
64.
For access, remove these FRUs in order:
• “1010 Removable battery” on page 64
• “1030 Base cover assembly” on page 65
Removal steps of the LCD bezel sheet
Chapter 9. Removing or replacing a FRU 93
To Next Page
