Step Screw (quantity) Color
Torque
7
M2 × 3 mm, flat-head, nylon-coated (2)
Black 0.181 Nm
(1.85 kgf-cm)
Step Screw (quantity) Color
Torque
9
M2 × 3 mm, flat-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgf-cm)
When installing:
Ensure that the hard disk drive or solid-state drive is firmly attached and the tape does not cover the speaker.
72
T480 Hardware Maintenance Manual
