• The screw 2e is available only in some computer models.
When installing:
• Ensure that the connector of the thermal fan is attached firmly.
• Before you attach the thermal fan assembly to the computer, apply thermal grease, at an amount of 0.2
grams, on the parts marked
a and b as shown in the following illustration. Either too much or too less
application of grease can cause a thermal problem due to imperfect contact with a component. For the
new thermal fan assembly, you must peel off the thin film from the rubbers.
– For integrated-graphics models
– For discrete-graphics models
Chapter 9. Removing or replacing a FRU 83
