Chapter
3.
Product overview
Front
1.
Integrated
camera activity
indicator
2. Integrated
microphones (2)
3.
Integrated
camera*
4. Infrared
camera*
5.
Screen
6. Wireless
charging pad**
7.
Internal
speakers
8. Wireless
charging indicator**
*
Either
an
integrated
camera
or
an
infrared
camera
is
provided on
your
computer.
**
for
selected
models
