Removalstepsofthehingesupportbracket,wirelessLANantennasassembly,andbasecover
assembly
Removethescrewsthatsecurethehingesupportbracket.Thenremovethehingesupportbracket.
1
1
1
2
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated(3)
Black0.181Nm
(1.85kgf-cm)
ReleasethewirelessLANantennasassemblyfromthetabsasshown.
4
4
3
3
3
3
3
3
