RemovethewirelessLANantennasassemblyfromthebasecoverassembly.
Antennalocations
a WirelessLANauxiliaryantenna(black)
b WirelessLANmainantenna(gray)
5b
5a
Attention:Whenyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncouldcause
thecablestobedamagedbythecableguides,orawiretobebroken.
Applyinglabelstothebasecover
ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveralkinds.Applythoselabelswhen
youreplacethebasecover.Forthelabelsthatarenotshippedwiththenewbasecover,peelthemofffrom
theoldbasecover,andadherethemtothenewone.
ThefollowingillustrationshowsthelocationofeachlabelforWindows7andWindows10basedcomputer
models.
1
2
3
4
5
7
6
9 8101112
13
14
15
16
17
18
19
IftheWindowsCertificateofAuthentication(COA)label 11 isattachedtoapartthatisreplaced,doone
ofthefollowing:
Chapter9.RemovingorreplacingaFRU83
