Lenovo ThinkPad S2 3rd Gen Hardware Maintenance Manual

Removal steps of the LCD bezel
When installing: Ensure that all the latches are attached firmly.
2090 LCD panel and LCD cable
For access, remove these FRUs in order:
• “1030 Base cover assembly” on page 78
• “1090 Battery pack” on page 83
• “1180 LCD unit” on page 92
• “2080 LCD bezel” on page 109
Removal steps of the LCD panel and LCD cable
Step Screw (quantity) Color
Torque
1
M2 × 2.5 mm, wafer-head, nylon-coated, small head (4) Black 0.181 Nm
(1.85 kgf-cm)
110 L380, L380 Yoga, S2 3rd Gen, and S2 Yoga 3rd Gen Hardware Maintenance Manual
