Lenovo ThinkPad S2 3rd Gen Hardware Maintenance Manual

When installing: Ensure that the LCD connector is attached firmly.
2100 LCD hinges
For access, remove these FRUs in order:
• “1030 Base cover assembly” on page 78
• “1090 Battery pack” on page 83
• “1180 LCD unit” on page 92
• “2080 LCD bezel” on page 109
• “2090 LCD panel and LCD cable ” on page 110
Removal steps of the LCD hinges
Step Screw (quantity) Color Torque
1
M2.5 × 2.5 mm, wafer-head, nylon-coated (6) Black 0.294 Nm
(3.0 kgf-cm)
Chapter 9. Removing or replacing a FRU 111
