1060 Coin-cell battery
For access, remove these FRUs in order:
• “1030 Base cover assembly” on page 78
Removal steps of the coin-cell battery
DANGER
Use only the authorized battery specified for your computer. Any other battery could ignite or
explode.
When installing: Ensure that the connector is attached firmly.
1070 Wireless LAN card
For access, remove these FRUs in order:
• “1030 Base cover assembly” on page 78
Removal steps of the wireless LAN card
In step
1 , unplug the connectors by using the antenna RF connector removal tool or pick the connectors
with your fingers and gently unplug them as shown.
Chapter 9. Removing or replacing a FRU 81
