Product overview
This section presents the following product-unique information:
v “Specifications”
v “Status indicators” on page 36
v “FRU tests” on page 39
v “Fn key combinations” on page 41
Specifications
The following table lists the specifications of the ThinkPad Z60t:
Feature Description
Processor v Intel Celeron M processor 360 (1.4 GHz), 1-MB L2 cache
v Intel Celeron M processor 370 (1.5 GHz), 1-MB L2 cache
v Intel Celeron M processor 380 (1.6 GHz), 1-MB L2 cache
v Intel Pentium M processor 740 (1.73 GHz), 2-MB L2 cache
v Intel Pentium M processor 750 (1.86 GHz), 2-MB L2 cache
v Intel Pentium M processor 760 (2 GHz), 2-MB L2 cache
v Intel Pentium M processor 770 (2.13 GHz), 2-MB L2 cache
v Intel Pentium M processor 780 (2.26 GHz), 2-MB L2 cache
Bus architecture v 533-MHz PSB
v 533-MHz DDR2 SDRAM (PC2-4200)
v HUB link
v PCI bus
v LPC bus
Graphic memory chip v Intel 915GM
Display v 14.0-inch wide, 16M colors, WXGA (1280 × 768 resolution)
TFT color LCD
Standard memory v 256-MB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 1
v 512-MB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 1
v 512-MB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 2
v 1-GB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 1
v 1-GB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 2
Optional memory v 256-MB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 1
v 512-MB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 1
v 1-GB DDR2-533 SDRAM SO-DIMM (PC2-4200) card × 1
(maximum of 2048 MB)
CMOS RAM v 242 bytes
Hard disk drive v 40.0 GB, 5400 rpm, 9.5 mm high, SATA interface
v 60.0 GB, 5400 rpm, 9.5 mm high, SATA interface
v 80.0 GB, 5400 rpm, 9.5 mm high, SATA interface
v 100 GB, 5400 rpm, 9.5 mm high, SATA interface
v 100 GB, 7200 rpm, 9.5 mm high, SATA interface
Supported
hard disk drives depend on the model.
Ultrabay Slim device
(standard)
v DVD drive, 9.5 mm high
v DVD/CD-RW combo drive, 9.5 mm high
v DVD-RAM/RW drive, 9.5 mm high
Fingerprint reader Some models
(continued)
Product overview
34 MT 2511, 2512, 2513, and 2514
