1020
Ultrabay
Slim
device
Note
Ultrabay
Slim
does
not
accept
any
of
the
following
devices:
v
Ultrabay
Plus
devices
v
Ultrabay
2000
devices
Note:
When
you
r
elease
the
switch
in
step
1
,
the
lever
pops
out.
In
step
2
,
pull
the
lever
a
little
to
r
elease
the
device
from
the
bay
.
1
2
3
Removing
and
replacing
a
FRU
ThinkPad
Z60t
57
62
64
