1070 Modem daughter card (MDC-1.5)
For access, remove these FRUs in order:
v “1010 Battery pack” on page 56
v “1040 Palm rest or palm rest with fingerprint reader” on page 60
v “1060 Keyboard” on page 63
2
1
1
Step Screw (quantity) Color Torque
1 M2 × 3 mm, flat-head, nylon-coated (2) Black 0.196 Nm
(2.0 kgfcm)
In step 2, remove the card by pulling the tab with your fingers in the direction
shown by the arrow.
(continued)
Removing and replacing a FRU
ThinkPad Z60t 65
