b.Positionthemicroprocessorsocketcoverabovethemicroprocessorsocketsothatthesmalltriangle
1onthesocketcoverfacesthesmalltriangle2onthemicroprocessorretainer.Then,carefully
pressthesocketcoverstraightdownintothesocketuntilitsnapsintoposition.
Figure141.Installingthemicroprocessorsocketcover
c.Gentlyclosethemicroprocessorretainer,pressdownthesmallhandle,andthenpushthesmall
handleinwardtolocktheretainerintoposition.
Figure142.Securingthemicroprocessorretainer
22.Installtheheatsinksonthenewsystemboard.See“Installingorreplacingaheatsink”onpage133.
23.Installthememorymodulesonthenewsystemboard.See“Installingamemorymodule”onpage98.
180ThinkServerRD430HardwareMaintenanceManual
