24.Notetheorientationofthepowersupplycoolingshroudandinstallitintothechassisbyinsertingthe
twosmalltabs1onthebottomoftheshroudintothecorrespondingholes2inthepowersupplycage.
Figure143.Installingthepowersupplycoolingshroud
25.Installthesystemboardbatteryonthenewsystemboard.See“Replacingthesystemboardbattery”on
page172
.
26.IfyouhaveaTMMPremium,installtheTMMPremiumonthenewsystemboard.See“Installingthe
TMMPremium”onpage123.
27.IfyouhaveaTPM,installtheTPMonthenewsystemboard.See“InstallingtheTPM”onpage126.
28.Installthetworisercardassembliesonthenewsystemboard.See“Replacingtherisercardassembly
1”onpage159and“Replacingtherisercardassembly2”onpage161.
29.Notetheorientationofthesystemfancage.Aligntheleftandrightsidesofthesystemfancagewiththe
correspondingmountingpostsinthechassis.Then,pressthesystemfancagewiththeinstalledsystem
fansstraightdownintothechassisuntilthesystemfancageiscorrectlyseatedandthesystemfansare
correctlyconnectedtothesystemfanconnectorsonthesystemboard.
Figure144.Installingthesystemfancagewithsystemfans
Chapter6.Installing,removing,orreplacinghardware181
