9.Removetheprotectivecoverthatprotectsthegoldcontactsonthebottomofthenewmicroprocessor.
Donottouchthepinsonthemicroprocessorsocketandthegoldcontactsonthebottomofthenew
microprocessor.
Figure91.Donottouchthepins
10.Notetheorientationofthenewmicroprocessor.Holdthenewmicroprocessorbyitsedgesandalign
thenotches1onitwiththetabs2inthemicroprocessorsocket.Then,carefullylowerthenew
microprocessorstraightdownintothemicroprocessorsocket.
Note:Thesmalltriangle3ononecornerofthenewmicroprocessoristhemicroprocessororientation
indicator.Thenewmicroprocessorisinthecorrectorientationwhenthisindicatorfacesthebeveled
corner
4ofthemicroprocessorsocket.
Figure92.Installingthemicroprocessor
138ThinkServerRD430UserGuide
